Icom IC-910H User Manual

39
5
RECEIVE AND TRANSMIT
D Setting keying speed
q Push [SET] then [SSB/CW] to enter the SSB/CW
set mode.
w Push [DN Z] or [Y UP] to select the keying speed
item.
 •“SPEEd”isdisplayed.
e Rotate the tuning dial to adjust the keying speed to
the desired speed.
 •Keyingspeedcanbeselectedfrom6–60wpm.
 •Push[M-CL5]for1sec.toreturntothedefaultvalue.
r Push [SSB/CW] to exit the SSB/CW set mode.
D Setting semi break-in function
q Push [SET] then [SSB/CW] to enter the SSB/CW
set mode.
w Push [DN Z] or [Y UP] to select the semi break-in
item.
 •“br-In”isdisplayed.
e Rotate the tuning dial to turn the semi break-in func-
tion ON and OFF.
 •Push[M-CL5]for1sec.toreturntothedefaultsetting.
r Push [DN Z] or [Y UP] to select the delay time item.
 •“dELAy”isdisplayed.
t Rotate the tuning dial to set the delay time to the
desired time period.
 •Delay time can be selected from 2.0–13.0sec. in
0.1 sec. steps.
 •Push[M-CL5]for1sec.toreturntothedefaultvalue.
y Push [SSB/CW] to exit the SSB/CW set mode.
D Setting keying weight
q Push [SET] then [SSB/CW] to enter the SSB/CW
set mode.
w Push [DN Z] or [Y UP] to select the keying weight
item.
 •“rAtio”isdisplayed.
e Rotate the tuning dial to adjust the keying weight
ratio to the desired level.
 •Keying weight ratio can be selected from 1:1:2.8 to
1:1:4.5.
 •Push[M-CL5]for1sec.toreturntothedefaultvalue.
r Push [SSB/CW] to exit the SSB/CW set mode.
D Setting CW pitch
q Push [SET] then [SSB/CW] to enter the SSB/CW
set mode.
w Push [DN Z] or [Y UP] to select the CW pitch item.
 •“Pitch”isdisplayed.
e Rotate the tuning dial to adjust the CW pitch to the
desired pitch.
 •CWpitchcanbeadjustedwithin300–900Hzrange.
 •Push[M-CL5]for1sec.toreturntothedefaultvalue.
r Push [SSB/CW] to exit the SSB/CW set mode.
D Setting side tone
q Push [SET] then [SSB/CW] to enter the SSB/CW
set mode.
w Push [DN Z] or [Y UP] to select the side tone item.
 •“SidE-t”isdisplayed.
e Rotate the tuning dial to adjust the side tone level to
the desired level.
 •Push[M-CL5]for1sec.toreturntothedefaultvalue.
r Push [SSB/CW] to exit the SSB/CW set mode.
KEYING WEIGHT EXAMPLE: Morse code “K”
DASH
Weight setting:
1:1:3 (default)
Weight setting:
Adjusted
DASH
DOT
(Fixed*)
Adjustable range SPACE (Fixed*)
*SPACE and DOT length can be adjusted with the
keying speed only.
