4-3 TRANSMIT ADJUSTMENTS
Touch [TX/ID] on the main adjustment menu screen.
ADJUSTMENT
ADJUSTMENT ITEM
DISPLAY
SETTING CONDITION OPERATION
IDLING
-Preparation-
1 – – Touch [ID] to enter to the TX idling
current adjustment mode.
2 VDL IDL Set • Receiving Touch [SET].
-Adjustment- 3 VHF ID SET • Automatically transmitted. Touch [SET].
(Two beeps sound after adjustment
of each item is completed.)
4 VHF FIDV
5 VHF DIDV
6 UHF ID SET
7 UHF FIDV
8 UHF DIDV
9 1.2G ID SET
10 1.2G FIDV
11 1.2G DIDV
VHF TX OUTPUT
POWER
-Preparation-
1 – • Connect the RF power meter to
the [144MHz ANT] connector.
• Connect the audio generator to
[MIC] connector, and set it to:
Frequency: 1.5 kHz
Waveform: Sine wave
Level: 30 mV rms
Touch [VHF] to enter to the VHF
output power adjustment mode.
-Adjustment- 2 TX POWER VHF SET • Receiving Touch [SET].
3 TX Total VHF Gain • Automatically transmitted. Set to 50 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
4 POWER VHF2 MIN Set to 0.5 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
5 POWER VHF2 1% Set to 1 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
6 POWER VHF2 10% Set to 10 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
7 POWER VHF2 50% Set to 50 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
8 POWER VHF2 100% Set to 100 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
VHF TX
BALANCE
-Adjustment-
1 POWER VHF Balance SET • Receiving Touch [SET].
2 POWER VHF1 100% • Automatically transmitted. Set to 100 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of each item is completed.)
3 POWER VHF3 100%
VHF AM CARRIER
POWER R ATE
-Adjustment-
1 POWER AM Ratio VHF • Receiving Touch [SET].
2 • Automatically transmitted. Set to 25 W by [MAIN DIAL], then
touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
VHF ALC
-Adjustment-
1 ALC VHF • Automatically transmitted. Touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
VHF DRIVE GAIN
-Adjustment-
1 DRIVE VHF • Automatically transmitted. Touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
4-5
