4-4 REFERENCE ADJUSTMENTS
Touch [REF] on the main adjustment menu screen.
ADJUSTMENT
ADJUSTMENT ITEM
DISPLAY
SETTING CONDITION OPERATION
REFERENCE
FREQUENCY
-Preparation-
1 – • Connect the 10 MHz reference
signal generator to the [REF IN
10 MHz] connector.
Touch [REF] to enter to the
reference frequency adjustment
mode.
-Adjustment- 2 REF OSC 1 • Set the 10 MHz reference signal
generator to:
Level: −10 dBm
• Receiving
Touch [SET].
(Two beeps sound after adjustment
of the item is completed.)
• After the adjustment, the transceiver shows the "REF OSC 2" adjustment item.
• Push [EXIT] twice to return to the main adjustment menu screen.
