6-1
[CHASSIS UNIT] [MAIN UNIT]
REF
NO.
PART
NO.
DESCRIPTION QT Y.
REF
NO.
PART
NO.
DESCRIPTION QT Y.
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
SP1 2510002001 057D0805-2 1
MF1 2710001060 FD128025HB-N (2N7R1) 1
W11 8600037690 SX3913 P11*P12CH (#3913-1) 1
W31 8600037700 SX3913 P31*P32CH (#3913-3) 1
W41 8600037710 SX3913 P41CH (#3913-4) 1
W21 8920003100 CAB-1377 1
W51 8920003070 CAB-1353 1
W101 8920003120 CAB-1355 1
W102 8920003110 CAB-1354 1
W111 8920003140 CAB-1357 1
W112 8920003110 CAB-1354 1
W121 8920003140 CAB-1357 1
W122 8920003110 CAB-1354 1
W123 8920003130 CAB-1356 1
W131 8920002430 CAB-1327 1
W201 8900016110 OPC-1680 (P0.5N30L100) 1
W202 8900016110 OPC-1680 (P0.5N30L100) 1
W203 8900016110 OPC-1680 (P0.5N30L100) 1
W204 8910000220 FFC-1024 (P0.5N40L120) 1
W205 8900016100 OPC-1678 (P0.5N12L80) 1
EP1 6910025930 S80-5 1
MP1 8010024560 3913 CHASSIS 1
MP2 8110011590 3913 A-PA COVER 1
MP3 8110011600 3913 C-PA COVER 1
MP4 8110011570 3913 U-COVER 1
MP5 8110011580 3913 L-COVER 1
MP6 8930079060 3073 DC PLATE 1
MP11 8930100220 3913 ANT PLATE 3
MP12 8820000530 FLANGE BOLT M4×8 NI 1
MP13 8850000140 FLAT WASHER M4 NI BS 2
MP14 8850000430 S-WASHER M4 NI 1
MP17 8810010580 SET SCREW A M4×32 4
MP18 8810008661 PH BT M3×8 NI-ZC3 6
MP20 8930100240 3913 NET 1
MP21 8810009061 FLAT M3×6 ZK3 18
MP32 8930002900 RUBBER LEG (A) SK1912A 2
MP33 8930074520 3015 STAND 1
MP34 8930075100 3015 STAND HOLDER 2
MP35 8810005771 BIND M3×8 ZK3 BLACK 4
MP36 8810009061 FLAT M3×6 ZK3 12
MP50 8930100230 3913 PLATE 2
MP51 8930093300 3765 SP RUBBER (TOP) 1
MP52 8810008661 PH BT M3×8 NI-ZC3 9
MP53 8810008661 PH BT M3×8 NI-ZC3 8
MP54 8810008661 PH BT M3×8 NI-ZC3 9
MP55 8810008661 PH BT M3×8 NI-ZC3 15
MP56 8810008661 PH BT M3×8 NI-ZC3 13
MP57 8810008661 PH BT M3×8 NI-ZC3 7
MP58 8810009651 FLAT BT M3×8 NI-ZC3 4
MP59 8810009050 SET SCREW H M3×10 NI 6
MP60 8810007131 SET SCREW H M3×6 ZC3 6
MP61 8950003640 CS-2 1
MP63 8930098820 INSULATION SHEET (OQ) 1
MP64 8930074910 SPONGE (JZ) 4
MP65 8930092000 SPONGE (NG) 2
MP66 8930092000 SPONGE (NG) 1
MP67 8930070510 THERMAL SHEET (BF) TC-600HS-1.4 1
MP68 8930076541 SHIELD SPONGE (CK)-1 2
MP69 8930078841 SHIELD SPONGE (CM)-1 1
MP70 8930076780 SPONGE (KE) 1
MP71 8930099320 SHIELD TAPE (AI) 1
MP72 8930099320 SHIELD TAPE (AI) 1
MP73 8930078841 SHIELD SPONGE (CM)-1 1
MP74 8930101630 SPONGE (QF) 1
MP75 8930018700 NONWOVEN SHEET Z 1
MP76 8930018700 NONWOVEN SHEET Z 1
MP77 8930018700 NONWOVEN SHEET Z 1
MP78 8930072800 INSULATION SHEET (LU) 1
MP79 8930093910 SPONGE (NV) 1
MP80 8930093910 SPONGE (NV) 1
MP81 8930093910 SPONGE (NV) 1
MP82 8930101700 FERRITE SHEET (BS) 1
MP83 8930097330 3818 FERRITE SHEET 1
MP84 8930101720 FERRITE SHEET (BT) 1
MP85 8930099310 SHIELD TAPE (AH) 1
MP86 8930099310 SHIELD TAPE (AH) 1
MP87 8930071690 PJ-13B [#13] 1
8930071690 PJ-13B [#15] 1
S171* 2230001480 LS37J2-T 1
T1901* 5920000990 H1102FNLT 1
BT251* 3020000390 ML414HIV01E 1
MP248 8510022750 3913 M-SHIELD PLATE [#13] 1
8510022750 3913 M-SHIELD PLATE [#15] 1
MP1001* 8510019780 3183 A-MAIN CASE 1
MP1002 8930082601 SHIELD SPONGE (CT)-1 [#13] 1
8930082601 SHIELD SPONGE (CT)-1 [#15] 1
MP2201* 8510022630 3913 AF CASE 1
MP7202* 8510021830 3765 S-CASE 1
MP7351* 8510021830 3765 S-CASE 1
MP7352* 8510017880 2844 MIX A-CASE 1
MP7353* 8510019650 3250 VCO CASE 1
MP7401* 8510021830 3765 S-CASE 1
MP7402* 8510017880 2844 MIX A-CASE 1
MP7403* 8510019650 3250 VCO CASE 1
MP8601* 8510020940 3537 D-SHIELD CASE 1
MP8602 8930101790 3913 SPONGE 1
MP8603 8930100110 SPONGE (PU) 1
MP8604 8930100110 SPONGE (PU) 1
MP8641* 8510022610 3913 SHIELD CASE 1
MP8661* 8510022670 4062 SHIELD CASE 1
MP8801 8930062740 2590 M-SPRING [#13] 1
8930062740 2590 M-SPRING [#15] 1
SECTION 6 MECHANICAL PARTS
[PA-A UNIT]
REF
NO.
PARTS
NO.
DESCRIPTION QT Y.
EP301* 6910020710 OT-047 M3 1
EP302* 6910020710 OT-047 M3 1
MP301* 8410003200 3913 A-CU HEATSINK 1
MP302* 8410003200 3913 A-CU HEATSINK 1
MP701* 8930094090 3768 ANT SPRING 1
REF
NO.
PART
NO.
DESCRIPTION QT Y.
F21* 5220000400 FHA010-01F 1
F22 5210000940 1205 1
EP21* 6910020710 OT-047 M3 1
EP22* 6910020710 OT-047 M3 1
EP62* 6910020710 OT-047 M3 1
EP63* 6910020710 OT-047 M3 1
MP301* 8410003200 3913 A-CU HEATSINK 1
[PA-B UNIT]
[PA- C UNIT]
REF
NO.
PART
NO.
DESCRIPTION QT Y.
MP61* 8510022620 OG-363065HD 1
MP81* 8410003200 3913 A-CU HEATSINK 1
MP141* 8510022620 OG-363065HD 1
MP161* 8510019650 3250 VCO CASE 1
MP231* 8510019650 3250 VCO CASE 1
MP271* 8510022610 3913 SHIELD CASE 1
MP361* 8510022610 3913 SHIELD CASE 1
