SECTION 1 SPECIFICATIONS

1-1

M General

• Frequency range:

RX/TX

144 MHz band (MHz) 430 MHz band (MHz) 1200 MHz band (MHz)

[USA], [EXP] 144.000000 ~ 148.000000 430.000000 ~ 450.000000

1240.000000 ~ 1300.000000

[EUR]

144.000000 ~ 146.000000

430.000000 ~ 440.000000

[KOR] 1260.000000 ~ 1300.000000

[ITR]

430.000000 ~ 434.000000

435.000000 ~ 438.000000

1240.000000 ~ 1245.000000

1270.000000 ~ 1298.000000

[TPE] 430.000000 ~ 432.000000 1260.000000 ~ 1265.000000

• Operating mode: A1A, A3E, J3E, F1B, F1D, F2D, F3E, F7W

• Number of memory channels: 107 (99 Simplexes+6 Program scan edges+2 Calls)×3 Bands

99 (Satellite memories)

• Power supply voltage: 13.8 V DC ±15%

• Polarity: Negative ground

• Antenna impedance: 50 Ω

• Power consumption: Stand-by

Maximum audio

Transmit (high power)

1.2 A (typical)

Less than 1.8 A

Less than 18 A

• Operating temperature range: −10ºC ~ +60ºC (14ºF ~ 140ºF)

• Frequency stability: ±0.5 ppm (−10ºC ~ +60ºC, 14ºF ~ 140ºF)

• Frequency resolution: Minimum 1 Hz

• Dimensions (projections not included): 240 (W)×94 (H)×238 (D) mm (9.4 (W)×3.7 (H)×9.4 (D) inches)

• Weight (approximate): 4.7 kg (10 Ib 6 oz)
