Icom IC-i7410 User Manual

106
CONTROL COMMAND
1
2
3
4
5
6
7
8
9
10
11
12
13
15
16
17
19
20
21
14
18
14
• Character code setting
Command : 1A 00
Character ASCII code Character ASCII code
A–Z 41–5A a–z 61–7A
0–9 30–39 Space 20
! 21 # 23
$ 24 % 25
& 26 \ 5C
? 3F " 22
’ 27 ` 60
^ 5E + 2B
– 2D
✱
2A
⁄ 2F . 2E
, 2C : 3A
; 3B = 3D
< 3C > 3E
( 28 ) 29
[ 5B ] 5D
{ 7B } 7D
¦ 7C _ 5F
¯ 7E @ 40
• Operating frequency
Command : 00, 03, 05
q
XXXXX
we
X
rt
XX XX
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit:
0 (fixed)
100 MHz digit:
0 (fixed)
• Operating mode
Command : 01, 04, 06
q
XXXX
w
q Operating mode w Filter setting
00: LSB 03: CW 07: CW-R 01: FIL1
01: USB 04: RTTY 08: RTTY-R 02: FIL2
02: AM 05: FM 03: FIL3
Filter setting (w) can be skipped with command 01
and 06. In that case, “FIL1” is automatically selected
with command 01 and the default filter setting of the
operating mode is selected with command 06.
• Band edge frequency setting
Command 02*, 1E 01, 1E 03
q
XXX
w ertyuio!0!1!2
XXXXXXXXX2DXXXXXXXXXX
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) Separator (fixed)
Lower edge Higher edge
Edge number*: 01–30
* Edge number setting is not necessary with com-
mand 02.
• Band stacking register
Command : 1A 01
q
XXXX
w
q Frequency band code
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000– 1.999999
02 3.5 3.400000– 4.099999
03 7 6.900000– 7.499999
04 10 9.900000–10.499999
05 14 13.900000–14.499999
06 18 17.900000–18.499999
07 21 20.900000–21.499999
08 24 24.400000–25.099999
09 28 28.000000–29.999999
10 50 50.000000–54.000000
11 GENE Other than above
w Register code
Code Registered No.
01 1 (latest)
02 2
03 3 (oldest)
For example, when reading the oldest contents in the
21 MHz band, the code “0703” is used.
When sending the contents, the codes, such as op-
erating frequency and operating mode*, should be
added after the register code, as shown above.
* See “Memory content setting (r to !8)” for details.
(p. 108)
D Data content description
