86
SET MODE
1
2
3
4
5
6
7
8
9
11
12
13
15
16
17
18
19
20
21
10
10
14
User Band Edge 7.
This “User Band Edge” item appears only when “ON
(User)”or“User(ON)&TX”isselectedinthe“Band
Edge Beep” item. (p. 85)
Whenyouselect“ON(User)”or“ON(User)&TX”in
the “Band Edge Beep” item, you can program a total
of 30 band edge frequencies in this item. See page 30
for programming details.
Beep Sound 8. (Default: 1000Hz)
Set a desired beep frequency for key operation to be-
tween 500 Hz and 2000 Hz in 10 Hz steps.
You can set the beep output level in
the “Beep Level”
item
. (p. 85)
RF/SQL Control 9. (Default: RF+SQL)
Set the [RF/SQL] control function.
•AUTO :[RF/SQL] functions as only an RF
gain control in SSB, CW and RTTY; a
squelch control in AM and FM.
•SQL :[RF/SQL]functions as a squelch con-
trol.
•RF+SQL :[RF/SQL]functions as an RF gain con-
trol as well as a noise squelch or an
S-meter squelch in FM; as an RF gain
control as well as an S-meter squelch in
SSB, CW, RTTY and AM.
Meter Peak Hold 10. (Default: ON)
Turn the Meter Peak Hold function ON or OFF.
When this function is set to ON, the peak level of a re-
ceived signal strength or the output power is displayed
for approximately 0.5 seconds.
TOT (CI-V) 11. (Default: OFF)
To prevent a prolonged transmission, the transceiver
has a Time-Out Timer function.
If a continuous transmission exceeds the set period,
the transmission will be cut off.
Set the time period to 3, 5, 10, 20 or 30 minutes, or
turn OFF the function.
NOTE: This function will be activated only when you
transmit using CI-V commands, or pushing [TRANS-
MIT] on the transceiver.
Quick SPLIT 12. (Default: ON)
Turn the Quick Split function ON or OFF.
When this item is set to ON, hold down [SPLIT] for 1
second to shift the transmit frequency from the receive
frequency, according to the “FM SPLIT Offset HF” or
“FM SPLIT Offset 50” setting as described below. See
page 67 for details.
FM SPLIT Offset HF 13. (Default: –0.100MHz)
Set the offset* to use the Quick Split function in the
HF bands.
*The difference between transmit and receive frequencies.
The frequency offset can be set to between –9.999
MHz and +9.999 MHz in 1 kHz steps.
FM SPLIT Offset 50 14. (Default: –0.500MHz)
Set the offset* to use the Quick Split function in the 50 MHz
bands.
*The difference between transmit and receive frequencies.
The frequency offset can be set to between –9.999
MHz and +9.999 MHz in 1 kHz steps.
SPLIT LOCK 15. (Default: OFF)
Turn the Split Lock function ON or OFF.
When this item is set to ON, you can use [DIAL] to ad-
just the transmit frequency while holding down [XFC],
even while the Dial Lock function is ON.
See pages 66, 67 for split frequency operation de-
tails.
Tuner (Auto Start) 16. (Default: OFF)
Turn the Automatic Antenna Tuner function ON or
OFF. This function is for only the HF bands.
•OFF:TheinternalantennatunerremainsOFFeven
when the SWR is high.
•ON :Theinternalantennatunerautomaticallystarts
tuning when the SWR is high, even if the tuner
is turned OFF.
To Next Page
