Ihse Draco U-Switch User Manual

Draco U-Switch Description
13
3.3 Chassis
Mounting Chassis
Chassis Power supply unit
Type Slots
Active
backplane Current input Internal External
Setup for redundant
power supply voltage
474-BODY2 2 No Interface side - 1x -
474-BODY2R 2 No Interface side - 1x 1x (external)
474-BODY2N 2 No Interface side 1x - 1x (external)
474-BODY4 4 No Interface side - 1x -
474-BODY4R 4 No Interface side - 1x 1x (external)
474-BODY6R-R1 6 No Interface side 1x - 1x (external)
Slide-in Chassis
Chassis Power supply unit
Type Slots
Active
backplane Current input Internal External
Setup for redundant
power supply voltage
474-BODY2BPF 2 Yes Interface side 1x - 1x (external)
474-BODY6BP 6 Yes Rear view 2x - -
474-BODY6BPF 6 Yes Interface side 2x - -
474-BODY21/4U 21 Yes Rear view 1x - 1x (internal)
474-BODY21/4UR 21 Yes Rear view 2x - -
All external power supply units are separately certified to the
relevant major international safety standards.
3.4 Product Types
Type Description
B476-4U4T Draco vario U-Switch Module 4-Port USB HID + 2.0
3.5 Add-on Module
Type Description
R474-BGX
Add-on module for CON Units with up to 8 configurable GPIO in-/outputs
