7 Operation
7.1 Switching via Keyboard
The MSC function contains a switching of the USB-HID control between different statically connected
sources and displays and can be performed via keyboard or mouse (see chapter 7.2, page 43).
To perform a switching operation via keyboard command, proceed as follows:
1. Enter the Hot Key to start the command mode.
The Caps Lock and Scroll Lock LEDs on the keyboard are flashing.
2. Enter the number of the specific source or display.
3. Press Enter to confirm.
At the same time the command mode is closed, the switching operation will be performed, and
keyboard and mouse are connected to the specified source or display.
When using the numeric keypad for switching, a confirmation of the switching operation by
pressing Enter
is not necessary.
The following keyboard commands are available for switching operations (e.g., using the numeric keypad):
Keyboard command
Function
Hot Key, Num0
Switch the USB-HID control to the own display (CON Unit with keyboard and
mouse)
Hot Key, Num1
Switch the USB-HID control to display 1
Hot Key, Num2
Switch the USB-HID control to display 2
Hot Key, Num3
Switch the USB-HID control to display 3
Hot Key, Num4
Switch the USB-HID control to display 4
