Ihse Draco U-Switch User Manual

Draco U-Switch Technical Data
61
12.6 Weight
The following table contains the weight when the respective chassis is fully equipped, for both the CPU Unit
and the CON Unit.
12.6.1 Weight of the Chassis
Chassis Weight Weight inclusive shipping box
474-BODY2 /
474-BODY2R
0.7 kg (1.5 lb) 2.5 kg (5.5 lb)
474-BODY2N 1.1 kg (2.4 lb) 2.9 kg (6.4 lb)
474-BODY4 /
474-BODY4R
0.9 kg (2.0 lb) 3.4 kg (7.5 lb)
474-BODY6R-R1 1.9 kg (4.2 lb) 5.1 kg (11.2 lb)
474-BODY6BP /
474-BODY6BPF
2.5 kg (5.5 lb) 3.5 kg (7.7 lb)
474-BODY21/4U 10.0 kg (22.1 lb) 14.5 kg (32.0 lb)
12.6.2 Weight of the U-Switch Module and Add-on Modules
Chassis Weight
B476-4U4T 107 g (0.24 lb)
R474-BGX 57 g (0.13 lb)
12.7 MTBF
Specific MTBF values (mean time between failure) can be requested from the manufacturer if required.
