Table of Contents Draco U-Switch
16
3.9 Device Views Draco vario Chassis
NOTICE
Exceeding the maximum permissible power consumption
In addition to the power consumption of the used modules, the power consumption of the connected
peripherals must be added.
 Note the maximum power consumption of the chassis (see chapter 12.3.1, page 59 and
chapter 12.3.2, page 59).
The device status of a
module is displayed via LED on the front side of following chassis:
474
-BODY2, 474-BODY2R, 474-BODY2N, 474-BODY4, 474-BODY4R and 474-BODY6R-R1.
3.9.1 2-Slot-Chassis Draco vario 474-BODY2
Fig. 4 Interface side chassis 474-BODY2
1 Slot 1
2
Slot 2
3 Power supply voltage, DC
3.9.2 2-Slot-Chassis Draco vario 474-BODY2R
Fig. 5 Interface side chassis 474-BODY2R
1 Slot 1
2
Slot 2
3 Power supply voltage 1, DC
4
Power supply voltage 2, DC
