3.9.8 6-Slot Chassis Draco vario 474-BODY6BP
Fig. 11 Interface side chassis 474-BODY6BP
1 Slot 1
2
Slot 2
3
Slot 3
4 Slot 4
5
Slot 5
6
Slot 6
Fig. 12 Rear view chassis 474-BODY6BP
1 Power supply voltage 1, AC
2
Power supply voltage 2, AC
3 Grounding
3.9.9 6-Slot Chassis Draco vario 474-BODY6BPF
Fig. 13 Interface side chassis 474-BODY6BPF
1 Slot 1
2
Slot 2
3
Slot 3
4
Slot 4
5 Slot 5
6
Slot 6
7
Power supply voltage 1, AC
8
Power supply voltage 2, AC
