Page 20 Operation Manual
A.4.3 Operating the Book Cradle
Note: Maximum load of each book cradle plate: 15 kg / 33 lbs
First lower both cradles to their home position. Place a book on the right plate, open the
book cover and raise the left cradle until it fully supports the left book cover. This is the
reference position.
Picture 6: Book cradle at start
If the optional glass plate is used, lift both cradles up until they reach the glass plate. Use
only the Cradles up / Cradles down keys for this, as they keep the balance between the
cradles. Move up until the glass plate is exactly horizontal, while manually applying some
pressure on the book.
Picture 7: Book cradle at start with glass plate option
