Page 66 Operation Manual
D Technical Data
D.1 Scanner Specifications
Scan Area
Maximum Scan Area [pixel] 7560 x 6442 pixels
Maximum Scan Area [mm] 640 x 520 mm
Optical Resolution 400 x 600 dpi
Resolution 150 – 600 dpi
Auto focus range 120 mm
Max. document thickness 120 mm / 90 mm (without / with glass plate)
Luminosity
Scanning 4500 LUX
Stand-by, idle 0 LUX (lamps off)
Lamps:
High Power White LED UV- and IR-radiation free
Lifetime 50.000 hours on-time
Book Cradle:
Maximum load / book cradle plate 15 kg / 33 lbs
D.2 Ambient Conditions
Operating Temperature +5 to +40° Celsius
Storage Temperature 0 to +60° Celsius
Relative Humidity 20 to 80% (non-condensing)
Ambient luminance ≥ 300 Lux
Noise Level < 50 dB(A) (Operating)
< 30 dB(A) (Stand-by)
