3.21 TECHNICAL DATA.
- Flue temperature values refer to an air inlet
temperature of 15°C and ow temperature of
50°C.
- The data relevant to domestic hot water
performance refer to a dynamic inlet pressure
of 2 bar and an inlet temperature of 15°C; the
values are measured directly at the boiler outlet
considering that to obtain the data declared
mixing with cold water is necessary.
- e max. sound level emitted during boiler
operation is < 55dBA. e sound level value is
referred to semianechoic chamber tests with
boiler operating at max. heat output, with
extension of ue gas exhaust system according
to product standards.
- * Specic capacity “D”: domestic hot water
ow rate corresponding to an average increase
of 30K, which the boiler can supply in two
successive withdrawals.
Victrix X 12 2 I Victrix X 24 2 I
Domestic hot water nominal heat input kW (kcal/h) 12,3 (10563) 26,7 (22933)
Central heating nominal heat input kW (kcal/h) 12,3 (10563) 24,1 (20747)
Minimum heat input kW (kcal/h) 2,0 (1753) 3,2 (2719)
Domestic hot water nominal heat output (useful) kW (kcal/h) 12,0 (10320) 26,0 (22360)
Central heating nominal heat output (useful) 12,0 (10320) 23,6 (20296)
Minimum heat output (useful) 1,9 (1634) 3,0 (2580)
Eciency 80/60 Nom./Min. % 97,7 / 93,2 97,8 / 94,9
Eciency 50/30 Nom./Min. % 106,9 / 102,4 106,7 / 103,0
Eciency 40/30 Nom./Min. % 107,0 / 106,8 108,1 / 107,1
Heat loss at casing with burner On/O (80-60°C) % 0,89 / 0,30 0,41 / 0,50
Heat loss at ue with burner On/O (80-60°C) % 0,02 / 2,00 0,02 / 2,00
Central heating circuit max. operating pressure bar 3 3
Central heating circuit max. operating temperature °C 90 90
Adjustable central heating temperature °C 20 ÷ 85 20 - 85
Total volume system heating expansion vessel l 5,7 5,7
Heating expansion tank factory set pressure bar 1,0 1,0
Water content in generator l 3,0 3,4
Total head available with 1000 l/h ow rate kPa (mm H
2
O) 6,7 (0,68) 25,8 (2,64)
*Specic capacity “D” UB Immergas 80 l (∆T 30°C) according to EN 625 l/min 17,2 20,5
*Specic capacity “D” UB Immergas 105 l (∆T 30°C) according to EN 625 l/min 21,0 24,8
*Specic capacity “D” UB Immergas 120 l (∆T 30°C) according to EN 625 l/min 21,1 27,1
*Specic capacity “D” UB Immergas 200 l (∆T 30°C) according to EN 625 l/min 22,1 35,7
Drawing capacity in continuous duty with UB Immergas (∆T 30°C) l/min 6,3 13,54
Weight of full boiler kg 39,5 42,4
Weight of empty boiler kg 36,5 39,0
Electrical connection V/Hz 230/50 230/50
Power input A 0,53 0,58
Installed electric power W 115 120
Pump consumption W 83 88
Fan consumption W 17 17
Equipment electrical system protection - IPX4D IPX4D
Flue gas max. temperature °C 75 75
NO
X
class - 5 5
Weighted NO
X
mg/kWh 19,0 36,0
Weighted CO mg/kWh 6,0 15,0
Type of appliance
C13 / C13x / C23 / C33 / C33x / C43 / C43x / C53 / C83 /
C93 / C93x / B33 / B53p
Category II2H3P
