Page 9
INF8630eAG / INF8630AG Hardware Guide
Side Panel Ports
Panel Front, Under, and Side
Front Panel Ports Front Panel Buttons
Light and Sensor
Optional PC Ports
Panel Back and Side
AV-OUT Y Pb Pr AV-IN L-IN R-IN USB3.0 USB3.0 USB2.0
SPDIF TOUCH-USB1 TOUCH-USB2 TOUCH-USB3 TOUCH-USB4 OPS PC-USB RS232-IN RS232-OUT
PC USB MEDIA USB
TOUCH USB HDMI
HDMI1 HDMI2 HDMI3 HDMI-OUT LAN HDMI4(MHL) VGA PC-AUDIO
Under Panel Ports
Trapezoid Plug In On/O Switch
To Next Page
