Page 14
Front Panel Ports
The front panel ports are located on the left side of the bottom front of the display. This table shows how to connect them.
PC USB MEDIA USB
TOUCH USB HDMI
Port
Name
Connection Instructions
Headset Connect a 3.5 mm headset to output audio. This will mute the internal speakers.
Mic Connect a 3.5 mm microphone or cable for audio input. Overrides audio from all other sources when connected.
PC USB Connect a USB 2.0 device to the OPS module.
Media
USB
Connect a USB 2.0 device to the Internal Android.
Touch
USB
Connect a USB A-B cable between this type B port and your computer to get touch control.
This works with front HDMI port.
HDMI Connect an HDMI cable from the display to an HDMI external device, such as a computer.
