7.4 RECOMMENDED SPARE PARTS LIST
I-R QTY
COMPRESSOR PART DESCRIPTION PART PER
NO. UNIT
Maintenance Kit (Units with Uncoded Tank) 42448456 1
Maintenance Kit (Units with ASME/CRN Coded Tank) 42474692 1
Ultra Coolant (5 gal.Container) 39433735 1
Air Filter Element 88171913 1
Coolant Filter 39329602 1
Coolant Separator Element (Uncoded Tank) 39900923 1
Coolant Separator Element - (ASME/CRN Coded Tank) 39912969 1
V-Belt, 42.5” 39204714 **
V-Belt, 45.0” 39204722 **
V-Belt, 47.5” 39204730 **
Inlet Valve Rebuild Kit 39257514 1
Inlet Valve O-Ring 95022117 1
Load Solenoid Valve (1SV) - NEMA 1 39583943 1
Load Solenoid Valve (1SV) - NEMA 4 39492566 1
Blowdown Solenoid Valve (3SV) 39492558 1
Shaft Seal Kit 42412197 1
Thermostatic Control Element 39441944 1
High Air Temperature Switch (HATS) 39416128 1
O-ring, HATS 39404157 1
Orifice, CheckValve / Filter 39303219 1
Combination Oil Cooler / Aftercooler 39899893 1
Minimum Pressure CheckValve (MPCV) 39490693 1
Hose, MPCV to Aftercooler In 39571872 1
Hose, Aftercooler Out to Receiver Tank (120 Gal.Tank) 39571922 1
Hose, Aftercooler Out to Receiver Tank (80 Gal.Tank) 39571963 1
Hose, Oil Filter to Airend Injection 39572003 1
Control Relay 39255559 2
Start Switch Operator 39255609 1
Start Switch Contact Block 39255633 1
Stop Switch Operator 39255625 1
Stop Switch Contact Block 39255641 1
Auto Restart Indicator Light 39255666 1
Power On Indicator Light 39243985 1
Auto Restart Timer Relay 39255567 1
Pressure Gauge 39499256 1
Pressure Switch 39439740 1
Starter Contactor Assembly, Size C16 39255518 1*
Starter Contactor Assembly, Size C23 39333257 1*
Starter Contactor Assembly, Size C30 39252010 1*
Starter Contactor Assembly, Size C43 39250998 1
Starter Contactor Assembly, Size C60 39251004 1
Reversing Starter Contactor Assy, Size C16 39255518 1*
Mechanical Interlock (Star-Delta) 39251186 1
Starter Overload Relay, EA5FB (1OL) 39255542 1
Starter Overload Relay, EA5GB (1OL) 39255591 1
Starter Overload Relay, EA5HC (1OL) 39251988 1
Starter Overload Relay, EA5JD (1OL) 39251079 1
Starter Overload Relay, EA5KE (1OL) 39251087 1
Auxiliary Contact, 2 N.O. 39255492 1
Hourmeter, 60 Hz 39226618 1
Hourmeter, 50 Hz 39233382 1
Relief Valve (Separator Tank) 39588082 1
Relief Valve (Receiver Tank) 39588017 1
Cooling Fan (7-1/2 & 10 HP) 39858485 2
Cooling Fan (15 HP) 39858485 3
Fuse, FU1 / FU2 39239355 2
Fuse, FU3 39113527 1
Control Circuit Transformer 39233408 1
Decal Kit (English) 39256730
* QUANTITY IS (2) FOR STAR-DELTA
** BELT SIZE AND QUANTITY VARYWITH HORSEPOWER AND PRESSURE RATING.CONTACT YOUR LOCAL INGERSOLL-RAND
DISTRIBUTOR IF ASSISTANCE IS NEEDED FOR BELT REPLACEMENT.
