Chapter 6 Description of Function Codes
- 57 -
Function
Code
Parameter Name Setting Range Default Min. Unit
F1-01 Rated motor power 0–750 W Model dependent 1 W
F1-02 Rated motor voltage 0–250 V 100 V 1 V
F1-03 Rated motor current 0.001–9.900 A Model dependent 0.001 A
F1-04 Rated motor frequency 1.00–99.00 Hz 24.00 Hz 0.01 Hz
F1-05 Rated motor speed 0–9999 RPM 180 RPM 1 RPM
Set the parameters according to the motor nameplate. Ensure that these motor parameters
are set correctly. Incorrect setting affects the motor auto-tuning and the vector control effect.
Function
Code
Parameter Name Setting Range Default Min. Unit
F1-06 Stator phase resistance of PMSM 0.00–99.99 Ω Model dependent 0.01 Ω
F1-07
Rotor phase resistance of
asynchronous motor
0.00–99.99 Ω Model dependent
0.01 Ω
F1-08
Leakage inductance of
asynchronous motor
0.0–99.99 mH Model dependent
0.01 mH
F1-09
Mutual inductance of asynchronous
motor
0–999.9 mH Model dependent
0.1 mH
F1-10
Magnetizing current of
asynchronous motor
0.001–9.900 A Model dependent
0.001 A
F1-11 Shaft D inductance of PMSM 0.0–999.9 mH Model dependent 0.1 mH
F1-12 Shaft Q inductance of PMSM 0.0–999.9 mH Model dependent 0.1 mH
F1-13 Back EMF of PMSM 0–250 Model dependent 1
F1-14
Encoder zero position angle of
PMSM
0.0–359.9° Model dependent
0.1°
F1-15 Real-time angle of PMSM 0.0–359.9° Model dependent 0.1°
Select a proper motor model according to the adaptable motor power. If there is a great
difference between the actual motor power and the adaptable motor power, the system control
performance will degrade.
F1-06 to F1-14 are updated automatically after motor auto-tuning is completed successfully.
For an asynchronous motor, the NICE900 obtains the corresponding parameters through
complete auto-tuning or static auto-tuning. If the onsite conditions does not allow motor auto-
tuning, manually input the value of these parameters by referring to data of the motor with the
same nameplate parameters.
Each time F1-01(Rated motor power) is changed, the controller automatically resumes
parameters F1-06 to F1-10 to the default values.
For a PMSM, the NICE900 can obtain F1-06 and F1-11 to F1-14 through complete auto-
tuning. After F1-01 is changed, the related parameters will not update.
F1-15 is used to display the magnetic pole position of the motor in real time.
