Functional Architecture Intel

Server Board S5500BC TPS

Intel order number: E42249-003 Revision 1.0

Table 4. Intel

Xeon

Processor 5500 Series Feature Set Overview

Feature Intel

Xeon

Processor 5500 Series

Cache Sizes Instruction Cache = 32 KB

Data Cache = 32 KB

8 MB shared among cores (up to 4)

Data Transfer Rate Two full-width Intel

QuickPath Interconnect links,

up to 6.4 GT/s in each direction.

Multi-Core Support Up to four cores per processor.

Dual Processor Support Up to two processors per platform.

Package 1366-land FCLGA

The Intel

Server Board S5500BC supports Intel

Xeon

processor 5500 series with 95 W

Thermal Design Power (TDP) or less and with a maximum data transfer rate of 6.4 GT/s.

3.1.1 Intel

QuickPath Interconnect (QPI)

Intel

QuickPath Interconnect (QPI) is a cache-coherent, link-based interconnect specification

developed by Intel to connect processor, chipset and I/O bridge components. The Intel

IOH

5500 chipset is the first dual-processor server/workstation platform to implement Intel

QuickPath Interconnect links. Figure 6 provides a platform overview of the Intel

IOH 5500

chipset with Intel

QuickPath Interconnect implementation.

The Intel

IOH 5500 chipset supports up to two processor sockets, with up to four cores per

socket. With Intel

QuickPath Interconnect, caching agents are responsible for participating in

the cache coherence protocol, and home agents are responsible for managing access to the

memory regions they control. Since the Intel

Xeon

processor 5500 series contains an

integrated memory controller, the home agents and caching agents reside within the processor

sockets. The Intel

QuickPath Interconnect link blocks include the Intel

QuickPath Interconnect

Physical through Protocol layers, which are implemented in hardware. No special software or

drivers are required, other than firmware to initialize the Intel

QuickPath Interconnect links and

load routing information.

Each the Intel

Xeon

processor 5500 series is connected to the other processor and the Intel

I/O Hub (IOH) chipset through dedicated Intel

QuickPath Interconnect links. Each Intel

QuickPath Interconnect link is a serial point-to-point connection, with 20 lanes per link under full

width operation. These links are the only mode of data exchange between the processors and

Intel

IOH chipset. There are no sideband signals. The Intel

QuickPath Interconnect

communication fabric is glueless and does not require special hardware to interface to the

processors to maintain cache coherency.
