Server Board S5500BC TPS Connector / Header Locations and Pin-outs
Revision 1.0 Intel order number: E42249-003 55
Pin Name Slot Name Pin
B34 PETxN4 GND A34
B35 GND PERxP4 A35
B36 GND PERxN4 A36
B37 PETxP5 GND A37
B38 PETxN5 GND A38
B39 GND PERxP5 A39
B40 GND PERxN5 A40
B41 PETxP6 GND A41
B42 PETxN6 GND A42
B43 GND PERxP6 A43
B44 GND PERxN6 A44
B45 PETxP7 GND A45
B46 PETxN7 GND A46
B47 GND PERxP7 A47
B48 PRSNT2# PERxN7 A48
B49 PE Strap GND A49
5.4 RMM3 Connector
The Intel
®
Sever Board S5500BC provides a connector (J3C1) to support a RMM3 card. The
RMM3 card provides the Integrated BMC with an additional dedicated network interface. The
dedicated interface uses a separate LAN channel. The RMM3 provides additional flash storage
for advanced features such as the WS-MAN. The following table shows the pin-out settings for
this connector.
Table 15. RMM3 Connector Pin-out (J3C1)
Pin Signal Name Pin Signal Name
1 P3V3 2 RMI_IBMC_MAC_MDIO
3 P3V3 4 RMII_IBMC_MAC_MDC
5 GND 6 RMII_IBMC_GCM4_RXD<1>
7 GND 8 RMII_IBMC_GCM4_RXD<0>
9 GND 10 RMII_IBMC_GCM4_CRS_DV
11 GND 12 CLK_50M_GCM4
13 GND 14 RMII_IBMC_GCM4_RX_ER
15 GND 16 RMII_IBMC_GCM4_TX_EN
17 GND 18 Key
19 GND 20 RMII_IBMC_GCM4_TXD<0>
21 GND 22 RMII_IBMC_GCM4_TXD<1>
23 P3V3 24 SPI_IBMC_BK_CS_N
25 P3V3 26 TP_GCM4_P26
27 P3V3 28 SPI_IBMC_BK_DO
29 GND 30 SPI_IBMC_BK_CLK
31 GND 32 SPI_IBMC_BK_DI
33 GND 34 FM_GCM4_PRSNT_N
