Installation Settings
During the first time installation, it is required to setup the installation
settings.
SETUP MODE ?
→ YES NO
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
1.Press LEFT arrow key to move cursor to YES and press OK key to enter setup mode.
2. Press arrow keys to move cursor to INSTALLATION and press OK key to enter
INSTALLATION menu.
+ANTENNA +SATELLITE
+SYSTEM →+INSTALLATION
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
OK
M
R
F
OK
M
R
F
3. Press UP and DOWN arrow keys to select the satellite that you wish to track and
press OK key to load the selected satellite.
SELECT SATELLITE
▲ [1] KOREA_5 113E ▼
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
OK
M
R
F
LATITUDE LONGITUDE HEADING
▲ 3
7.00N ▼ 126.53E 000.0
1
4
7
2
5
8
3
6
9
←
0
·
Antenna Control Unit
4. Set LATITUDE, LONGITUDE and SHIP’S HEADING
Press LEFT and RIGHT arrow keys until the desired character is underscored
(selected). Press UP and DOWN arrow keys to increase or decrease the value.
Or press NUMBER keys to set the desired value directly. Press OK key to set the
parameter.
Entry of ships heading is not required when your system is connected to a NMEA0813
or 1:1 Synchro Heading Gyro Compass output.
OK
M
R
F
Operating the ACU
