Intellian V110 User Manual

77 Appendix
Appendix : v110 Technical Specification
General
Approvals
CE – conforms to
FCC – verified to
EU Directive 89/336/EEC
CFR47:Part 15
Dimensions
Satellite antenna unit
Antenna dish diameter
Antenna control unit
146.8 cm x 151.7 cm (57.8” x 59.7”)
105cm (41.3")
43cm x38cm x4.37cm (16.9”x14.9”x1.7”)
Weight
Satellite antenna unit
Antenna control unit
150kg (330 lbs)
5.2kg (11.5 lbs)
Antenna system performance
Tx Frequency 14.0 ~ 14.5 GHz Ku-band
Tx Gain 41.3 dBi @ Mid band
Rx Frequency 10.95 ~ 12.75 GHz Ku-band
Rx Gain 40.2 dBi @ Mid band
Polarized Feed Cross-pol or Co-pol
Skew Control Automatic Skew-angle Control
Azimuth range Unlimited
Elevation range -15° ~ +120°
Cross-level range +/- 37°
Stabilization Accuracy
0.2° peak mis-pointing @ max ship
motion condition
Max Ship’s motion
+/-25°roll, +/- 15° pitch, +/-8° yaw @ 6
sec
Turning rate Up to 12°/ sec & 5°/ sec
2
BUC 4W, 6W, 8W (optional)
Rack Mount Antenna Control Unit
Display 2 Line 40 Character Graphic VFD Module
Serial Interface 19200bps 8, N, 1, RS-232C
Modem Interface
Ethernet port / RS-232C / I/O ports
