DIAGNOSIS COMMUNICATION

CODE 101 RESULT : PASSED

←

Antenna Control Unit

6. The diagnosis result is shown.

Diagnosis Code :

CODE 101 : The data communication between the antenna and the ACU is tested.

CODE 102 : The azimuth motor is tested.

CODE 103 : The elevation motor is tested.

CODE 104 : The cross-level motor is tested.

CODE 105 : The azimuth encoder is tested.

CODE 106 : The cross-level encoder is tested.

CODE 107 : The gyro sensor is tested.

CODE 108 : The tilt sensor is tested.

CODE 109 : The sensor box motor is tested.

CODE 110 : The LNB is tested .

CODE 111 : The LNB skew motor is tested.

CODE 112 : The sub-reflector is tested.

CODE 113 : The antenna power is tested.

CODE 114 : The ACU power is tested.

CODE 115 : The receiver power is tested.

Test Result : ●2●●●●●●●●●-●●-

● Test means passed.

– Test means skipped. (112 and 115 will only be applied to Intellian TVRO antenna systems)

? Test means under process.

2 Refer to diagnosis code 102 as shown above for occurred error explanation.

Operating the ACU

Intellian V110 User Manual
