INVT GD20-0R4G-S2 User Manual

Goodrive20 inverters Function Parameters
44
Function
code
Name Detailed instruction of parameters
Default
value
Modify
constant power
zone
power. The motor will enter into the weakening state when
the motor runs at rated speed. Change the weakening curve
by modifying the weakening control coefficient. The bigger
the weakening control coefficient is, the steeper the weak
curve is.
The setting range of P03.22:0.1~2.0
The setting range of P03.23:10%~100%
P03.23
The lowest
weakening
point in
constant
power
zone
20% ○
P03.24
Max. voltage
limit
P03.24 set the Max. Voltage of the inverter, which is
dependent on the site situation.
The setting range:0.0~120.0%
100.0%
◎
P03.25
Pre-exciting
time
Pre-activate the motor when the inverter starts up. Build up
a magnetic field inside the motor to improve the torque
performance during the starting process.
The setting time:0.000~10.000s
0.300s ○
P03.26
Weakening
proportional
gain
0~8000 1200 ○
P03.27
Speed
display
selection of
vector control
0: Display at the actual value
1: Display at the setting value
0 ○
P04 Group SVPWM control
P04.00
V/F curve
setting
These function codes define the V/F curve of Goodrive20
motor 1 to meet the need of different loads.
0:Straight line V/F curve；applying to the constant torque
load
1: Multi-dots V/F curve
2: 1.3th power low torque V/F curve
3: 1.7th power low torque V/F curve
4: 2.0th power low torque V/F curve
Curves 2~4 apply to the torque loads such as fans and
water pumps. Users can adjust according to the features of
the loads to get the best performance.
5:Customized V/F(V/F separation); in this mode, V can be
separated from f and f can be adjusted through the
frequency given channel set by P00.06 or the voltage given
channel set by P04.27 to change the feature of the curve.
Note: V
b
in the below picture is the motor rated voltage and
f
b
is the motor rated frequency.
0 ◎
