INVT GD20-0R4G-S2 User Manual

Goodrive20 inverters Function Parameters
84
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P14.08
Reserved
●
P17 Group Monitoring function
P17.00
Setting
frequency
Display current set frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.01
Output
frequency
Display current output frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.02
Ramp
reference
frequency
Display current ramp reference frequency of the inverter
Range: 0.00Hz~P00.03
●
P17.03
Output voltage
Display current output voltage of the inverter
Range: 0~1200V
●
P17.04
Output current
Display current output current of the inverter
Range: 0.0~5000.0A
●
P17.05
Motor speed
Display the rotation speed of the motor.
Range: 0~65535RPM
●
P17.06
Torque current
Display current torque current of the inverter
Range: 0.0~5000.0A
●
P17.07
Magnetized
current
Display current magnetized current of the inverter
Range: 0.0~5000.0A
●
P17.08
Motor power
Display current power of the motor.
Setting range: -300.0%~300.0%
(the rated current of the motor)
●
P17.09
Output torque
Display the current output torque of the inverter.
Range: -250.0~250.0%
●
P17.10
The motor
frequency
evaluation
Evaluate the motor rotor frequency on open loop vector
Range: 0.00~ P00.03
●
P17.11
DC bus voltage
Display current DC bus voltage of the inverter
Range: 0.0~2000.0V
●
P17.12
Switch input
Display current Switch input terminals state of the inverter
●
