INVT GD20-0R4G-S2 User Manual

Goodrive20 inverters Function Parameters
74
Function
code
Name Detailed instruction of parameters
Default
value
Modify
1: Stop integral adjustment when the frequency reaches the
upper and low limit. If the integration keeps stable, and the
trend between the reference and the feedback changes, the
integration will change with the trend quickly.
LED tens:
0:The same with the setting direction; if the output of PID
adjustment is different from the current running direction,
the internal will output 0 forcedly.
1:Opposite to the setting direction
LED hundreds:
0: Limit to the maximum frequency
1: Limit to A frequency
LED thousands:
0:A+B frequency, buffer ACC/DEC is invalid for the main
reference A frequency source
1:A+B frequency, buffer ACC/DEC is valid for the main
reference A frequency source and the ACC/DEC is
determined by time 4 of P08.04
P09.14
Proportional
gain at low
frequency (Kp)
0.00~100.00 1.00 ○
P09.15
PID command
of ACC/DEC
time
0.0~1000.0s 0.0s ○
P09.16
PID output filter
time
0.000~10.000s 0.000s ○
P10 Group Simple PLC and multi-step speed control
P10.00
Simple PLC
means
0: Stop after running once. The inverter has to be
commanded again after finishing a cycle.
1: Run at the final value after running once. After finish a
signal, the inverter will keep the running frequency and
direction of the last run.
2: Cycle running. The inverter will keep on running until
receiving a stop command and then, the system will stop.
0 ○
P10.01
Simple PLC
memory
selection
0:Power loss without memory
1:Power loss memory；PLC record the running stage and
frequency when power loss.
0 ○
P10.02
Multi-step
speed 0
100.0% of the frequency setting corresponds to the Max.
Frequency P00.03.
0.0%
○
