LBK System Series| Instruction manual v1.2 SET 2021 |SAF-UM-LBKBus-en-v1.2|© 2020-2021 Inxpect SpA
7. Maintenance and troubleshooting
7.4.2 Temperature errors (TEMPERATUREERROR)
Error Meaning
BOARD TEMPERATURE TOOLOW Board temperature below minimum
BOARD TEMPERATURETOOHIGH Board temperature above maximum
7.4.3 Control unit voltage errors (POWERERROR)
Error Meaning
Control unit voltage
UNDERVOLTAGE
Undervoltage error for the indicated voltage
Control unit voltage
OVERVOLTAGE
Overvoltage error for the indicated voltage
ADC CONVERSION
ERROR
(only for the ADC) ADC conversion error in the micro-controller
The following table describes the control unit voltage:
Screen printing Description
VIN Power supply voltage (+24 V dc)
V12 Internal supply voltage
V12 sensors Sensors power supply voltage
VUSB USB port voltage
VREF Inputs reference voltage (VSNS Error)
ADC Analog-digital converter
7.4.4 Peripheral error (PERIPHERAL ERROR)
Error detected by diagnostics relative to the micro-controller, its internal peripherals or memories.
7.4.5 Configuration errors (FEE ERROR)
Indicates that the system must still be configured. This message can appear when the system is first turned on or
after reset to default values. It can also represent another error on the FEE (internal memory).
7.4.6 Output errors (OSSD ERROR)
Error Meaning
OSSD 1 SHORT
CIRCUIT
Short-circuit error on MOS output 1
OSSD 2 SHORT
CIRCUIT
Short-circuit error on MOS output 2
OSSD 3 SHORT
CIRCUIT
Short-circuit error on MOS output 3
OSSD 4 SHORT
CIRCUIT
Short-circuit error on MOS output 4
OSSD 1 NOLOAD No load detected on MOS output 1
OSSD 2 NOLOAD No load detected on MOS output 2
OSSD 3 NOLOAD No load detected on MOS output 3
OSSD 4 NOLOAD No load detected on MOS output 4
OSSD 1-2 CROSS
CHECK
Short-circuit error between MOS output 1 and 2
OSSD 1-3 CROSS
CHECK
Short-circuit error between MOS output 1 and 3
OSSD 1-4 CROSS
CHECK
Short-circuit error between MOS output 1 and 4
