ITech IT8200 Series User Manual

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 129
CP Mode
Range
Max. Power
（ 1phase/3phase ）
135k
W
Max. Power
（ reverse phase )
90k
W
Per Phase
(3phase )
45k
W
Resolution
0.1
kW
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
AC Mode
CS Mode
Range
Max. Power
（ 1phase/3phase ）
135k
VA
Max. Power
（ reverse phase )
90k
VA
Per Phase
(3phase )
45k
VA
Resolution
0.1
kVA
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
CR Mode
Range
1phase
0.04 ～ 44
Ω
Per Phase
(3phase )
0.12 ～ 130
Ω
reverse phase
0.23 ～ 260
Ω
Resolution
0.001
Ω
Accuracy*5
.
0.4%+0.4%F.S.
Ω
Circuit Emulation(CE)-Parallel rlc
R Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
L Range
1phase
1 ~ 2000
uH
reverse phase
3 ~ 2000
3phase
3 ~ 2000
C Range
1phase
0.001 ~ 9900
uF
reverse phase
0.001 ~ 3300
3phase
0.001 ~ 3300
Rc Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
RL Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
IL Range
1phase
0 ~ 272.7
A
reverse phase
0 ~ 90.90
3phase
0 ~ 90.90
Max peak current
1phase
272.7
A
reverse phase
90.9
3phase
90.9
Circuit Emulation(CE)-Rectifier single phase rlc
R Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
L Range
1phase
0.1 ~ 2000
uH
reverse phase
0.3 ~ 2000
3phase
0.3 ~ 2000
C Range
1phase
0.001 ~ 9900
uF
reverse phase
0.001 ~ 3300
3phase
0.001 ~ 3300
R S Range
1phase
0 ~ 1000
Ω
reverse phase
0 ~ 3000
3phase
0 ~ 3000
Vcap Range
1phase
0 ~ 499.924
V
reverse phase
0 ~ 499.924
3phase
0 ~ 499.924
Vdiode RangeL
1phase
0 ~ 5
V
reverse phase
0 ~ 5
3phase
0 ~ 5
Max peak current
1phase
272.7
A
reverse phase
90.9
3phase
90.9
Phase Range
Range
Rectified Mode *6
-82.8º~+82.8º
°
-90º~+90º
Resolution
0.01
°
Accuracy
1% F.S.
°
CF Setting
Range
1.414 ~ 5.0
Resolution
0.001
DC Mode
Voltage Range
30 ~ 499
V
Current Range
1phase
0 ～ 810
A
Current Rise time
200
us
work mode
CC, CV, CR, CP ， CC+CV ， CR+CV ， CP+CV ， CC+CR ， CC+CV+CP+CR
Measurement parameter
Range
0 ～ 350
Vrms
