Instrument Introduction
Copyright ©ITECH Electronic Co., Ltd. 19
Test report before delivery.
NOTE
After confirming that package contents are consistent and correct, please appropriately
keep package box and related contents. The package requirements should be met when
the instrument is returned to factory for repair.
The IT8230-350-180 model comes with a yellow optical fiber cable. The fiber cable need
to install by yourself. For details, see 3.3 chapter.
2.3 Front Panel
The front panel of IT8200 is as shown below.
2 USB interface /Print/Trig/Menu
6 Up, down, left and right key and enter key
2.4 Keyboard
The keyboard introduction of IT8200 series Instrument is shown as follows.
Used for saving screen images
Used for going back to menu page
