*1 ( 200
～
220 ) ±10%, 3 phase AC input, 60% of the rated power output for 12Kw and above models.
*2 Under the output frequency of 50Hz/60Hz, the maximum CF is 5 without exceeding the peak current; under the condition of full current and full
power, the maximum CF is 3.
*3 When frequency <150Hz, the minimum current for test need to be 1%F.S. frequency >150Hz, the minimum current for test need to be 3%F.S.
*4When loopSpeed Low is low
，
it can better complied DUT's characteristics
；
When LoopSpeed is High
，
the dynamic response time is
*5 Frequency <150Hz, the specification is meet.
*6 In the rectifier load mode, the setting range of phase Angle is related to CF. The larger CF is, the larger the range of phase Angle can be set.
9.2 Supplemental characteristics
Recommended calibration frequency: once a year
Cooling style: fans
