ITech IT8200 Series User Manual

Technical Specifications
Copyright ©ITECH Electronic Co., Ltd. 131
Input Frequency
DC ， 16~500
Hz
Input current
RMS （ 1phase ）
900
A
Crest Factor *2
5
Peak （ 1phase ）
2700
A
RMS
(3phase/reverse)
300
A
Peak
(3phase/reverse )
900
A
Input power
Per Phase
(3phase )
50k
VA
Max. Power
（ reverse phase )
100k
VA
Max. Power
（ 1phase/3phase ）
150k
VA
CC Mode
Current Range
RMS
（ 1phase ）
900
A
RMS
(3phase/reverse)
300
A
Resolution
0.1
A
Accuracy*3
DC,16Hz ～ 150Hz
＜ 0.1% + 0.2%
F.S.
A
150.01Hz ～ 500Hz
*4
＜ 0.2% + 0.3%
F.S.
A
Temperature coefficient
< 200ppm/ ℃ F.S
CP Mode
Range
Max. Power
（ 1phase/3phase ）
150k
W
Max. Power
（ reverse phase )
100k
W
Per Phase
(3phase )
50k
W
Resolution
0.1
kW
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
AC Mode
CS Mode
Range
Max. Power
（ 1phase/3phase ）
150k
VA
Max. Power
（ reverse phase )
100k
VA
Per Phase
(3phase )
50k
VA
Resolution
0.1
kVA
Accuracy
DC,16Hz ～ 500Hz
＜ 0.4% +0.4%
F.S.
Temperature
< 200ppm/ ℃ F.S.
CR Mode
Range
1phase
0.04 ～ 39
Ω
Per Phase
(3phase )
0.1 ～ 117
Ω
reverse phase
0.2 ～ 234
Ω
Resolution
0.001
Ω
Accuracy*5
.
0.4%+0.4%F.S.
Ω
Circuit Emulation(CE)-Parallel rlc
R Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
L Range
1phase
1 ~ 2000
uH
reverse phase
3 ~ 2000
3phase
3 ~ 2000
C Range
1phase
0.001 ~ 9900
uF
reverse phase
0.001 ~ 3300
3phase
0.001 ~ 3300
Rc Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
RL Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
IL Range
1phase
0 ~ 272.7
A
reverse phase
0 ~ 90.90
3phase
0 ~ 90.90
Max peak current
1phase
272.7
A
reverse phase
90.9
3phase
90.9
Circuit Emulation(CE)-Rectifier single phase rlc
R Range
1phase
0.33 ~ 1000
Ω
reverse phase
1 ~ 3000
3phase
1 ~ 3000
L Range
1phase
0.1 ~ 2000
uH
reverse phase
0.3 ~ 2000
3phase
0.3 ~ 2000
C Range
1phase
0.001 ~ 9900
uF
reverse phase
0.001 ~ 3300
3phase
0.001 ~ 3300
