OPERATION 5
en-57
5.12 TO REMOVE A BLOCKAGE FROM CUTTING IMPLEMENTS _______________________
1. Stop and lift the cutter implements before you move the machine to level ground.
2. Turn off the engine and remove the ignition key.
3. Wear the personal protective equipment that is applicable for this work, for example eye protection, gloves and
correct footwear. Use Bat (4184540), to remove the blockage.
4. Check the blades for damage and replace if necessary.
5. Start the engine and run the cutter implements to check for correct operation.
5.13 SLINGING AND JACKING THE MACHINE ______________________________________
Slinging
When slinging the machine a set of four damage free wheel clamps must be used,
similar to the one shown, in conjunction with a certified lifting frame.
WARNING
To reduce the risk of injury and infection from foreign objects always use the Bat (4184540) and heavy
duty leather gloves to remove a blockage from cutting implement.
!
