Page 30
10.3 ProTouch™ Glass Control Panel
Your Jacuzzi Spa is equipped with a state-of-the-art touch screen control
panel. The control panel complements the contemporary and sleek
design of your spa. Access to all menus can be achieved by using the
touch screen. Programming features can be easily programmed with our
user-friendly design. With the ease of use, there will more time to enjoy
the benets of your spa.
A. Home Menu Control Buttons
The Home Menu, Figure 10.3a, provides access to spa functions and
programming. Operation is made easy by the interactive touch-screen
control panel. If there is no activity for 5 minutes, the LCD display will
time-out into a sleep mode. To reactivate the display, just swipe across
the top from one corner to the other, Figure 10.3b.
NOTE: When a feature is on, the button will have a blue highlight around it.
= Temperature Control: Allows you to adjust the set
temperature of the spa:
• Increase the temperature by tapping
in 1° increments.
• Decrease the temperature by tapping in 1° increments.
Note: The temperature range for the spa is 65 to 104°F (18.33 to 40°C).
To activate the Extended Temperature feature that allows the spa to
reach 106°F (41°C), see page 67.
= Jet Button: Tap to access the menu to operate the jets pump,
page 32.
= Light Button: Tap to access the menu to operate the various
lighting options, page 33.
= Music Button: Tap to access the menu to operate the audio
system and settings, page 35.
Note: If the spa does not have the stereo option, there will not be a
button on the control panel.
= CLEARRAY Button: Tap to activate the CLEARRAY on
demand feature, page 38.
96
6:45 PMON UV
Figure 10.3a
Figure 10.3b
