Jacuzzi J-585 User Manual

Page 73
18.3 Dip Switch Settings
The dip switches are at the S1 location on the board.
A. Switch settings for Domestic 60Hz Models
BREAKER
DIP SWITCH NUMBER
1 2 3 4 5 6 7 8 9 10
40A OFF OFF OFF OFF OFF OFF OFF OFF OFF OFF
50A* OFF OFF ON OFF OFF OFF OFF OFF OFF OFF
60A OFF OFF OFF ON OFF OFF OFF OFF OFF OFF
*50A is the factory default setting
B. Switch settings for Export 50Hz Models
BREAKER
DIP SWITCH NUMBER
1 2 3 4 5 6 7 8 9 10
1x20A ON OFF OFF ON ON OFF OFF OFF OFF OFF
1x16A/
1x20A*
ON OFF ON OFF ON OFF OFF OFF OFF OFF
1x32A ON OFF ON ON OFF OFF OFF OFF OFF OFF
3x16A ON OFF OFF ON OFF OFF OFF OFF OFF OFF
*1x16A/1x20A is the factory default setting
DOMESTIC DIP SWITCH SETTINGS
S1 LOCATION
40A
50A
(factory default)
60A
1
2
3
4
5
6
7
8
9
10
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ONOFF
1
2
3
4
5
6
7
8
9
10
OFF
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
ONOFF
1
2
3
4
5
6
7
8
9
10
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
ONOFF
EXPORT DIP SWITCH SETTINGS S1 LOCATION
1x20A 1x16A/1x20A
(factory default)
1x32A
1
2
3
4
5
6
7
8
9
10
ON
OFF
ON
OFF
ON
OFF
OFF
OFF
OFF
OFF
ONOFF
1
2
3
4
5
6
7
8
9
10
ON
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
OFF
ONOFF
1
2
3
4
5
6
7
8
9
10
ON
OFF
OFF
ON
ON
OFF
OFF
OFF
OFF
OFF
ONOFF
3x16A
1
2
3
4
5
6
7
8
9
10
ON
OFF
OFF
ON
OFF
OFF
OFF
OFF
OFF
OFF
ONOFF
