jotron TR-910 User Manual

CONTENTS
Contents
1 Introducon 11
1.1 Design ............................................... 11
1.2 Applicaons............................................ 11
1.3 Models covered by this manual .................................. 11
1.4 Opons .............................................. 13
2 Technical Specificaons 14
2.1 General specificaons....................................... 14
2.2 Transmier specificaons..................................... 15
2.3 Receiver specificaons ...................................... 16
2.4 Applicable standards ....................................... 17
3 Funconal Descripon 18
3.1 Front panel controls and connector ................................ 18
3.1.1 Display .......................................... 18
3.1.2 Scroll/Select knob ..................................... 19
3.1.3 Shortcut keys ....................................... 20
3.1.4 Mic/Headset connector (RJ45) .............................. 20
3.2 Rear connecons ......................................... 21
3.2.1 Antenna connector (50 Ω BNC) .............................. 21
3.2.2 DC input connector .................................... 21
3.2.3 LAN connector (RJ45) ................................... 22
3.2.4 I/O connector (RJ45) ................................... 22
4 Installaon 24
4.1 Introducon............................................ 24
4.2 Inial inspecon.......................................... 24
4.3 Compass safe distance ...................................... 24
4.4 Installaon of TR-910 ....................................... 25
4.4.1 TR-910 Desktop Radio (DE) ................................ 25
4.4.2 TR-910 Man Portable Radio (MP) ............................ 26
4.4.3 TR-910 Vehicle Radio (VE) ................................ 30
4.4.4 TR-910 Last Resort Radio (LR) .............................. 31
4.4.5 TR-910 Subrack Radio (SR) ................................ 32
4.4.6 TR-910 Last Resort Subrack Radio (LR-SR) ........................ 33
4.4.7 TR-910 Offshore Radio (OF) . . ............................. 34
4.4.8 Antenna connecon ................................... 35
4.4.9 DC supply connecon................................... 35
4.4.10 LAN connecon...................................... 35
4.4.11 I/O connecon ...................................... 35
5 Operang Instrucons 37
5.1 Introducon............................................ 37
5.2 Note on frequency seng .................................... 37
5.3 Basic Operaon.......................................... 39
5.3.1 Turning the unit ON/OFF ................................. 39
10 jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB

jotron TR-910 Specifications

General

Brand	jotron
Model	TR-910
Category	Radio
Language	English
