2.1 General specificaƟons
2 Technical Specificaons
2.1 General specificaons
Table 10: General specificaons
Parameter Specificaons
AM 25 kHz AM 8.33 kHz
Frequency range 118.000 to 137.000 MHz (up to 144.000 MHz is oponal)
Frequency stability < ± 1.0 ppm @ -20 °C to +55 °C,
< ± 0.3ppm@0°Cto+40°C(ambient temperature)
RF Modes 6K80A3EJN 5K00A3EJN
Audio Frequency Response 300 - 3400 Hz 300 - 2500 Hz
Data ports 100Base-TX (Ethernet/LAN), USB 2.0 (for service / setup only)
Ethernet ports 1 x 100 Mbit network
Protocols UDP/IP: SNMP (v.1, 2 and 3), RTP, SIP, NTP, TFTP, DHCP, RTSP
TCP/IP: Remote control (Jotron), RTP, SIP, HTTP, RTSP
Serial: USB 2.0
BITE monitoring All relevant parameters for transceiver. Ref. BITE below.
Pre-set channels 100
RF impedance 50 Ω, BNC-connector
Temperature range -20 °C to +55 °C (operang), -40 °C to +70 °C (storage)
Humidity 95 % @ +40 °C (non-condensing)
Operang voltage 12 - 24 VDC, negave ground +30/-10 %
Power consumpon At 10 W, 80 % modulaon: < 60 W
At idle: < 5.0W@12V,<5.6W@28V
At standby: < 1.3 mW @ 12 V, < 7.2 mW @ 28 V
Heat dissipaon <5W@Idle, < 50W@10Woutput power
MTBF (MIL-HDBK-217F) Ground Benign (GB): > 20 years / unit
Ground Mobile (GM): > 10 years / unit
MTTR < 30 minutes at lowest replaceable unit
Dimension 169 mm (W) * 244 mm (D) * 55 mm (H)
Weight 1.95 kg
Start-up me <10sfrompoweronunl transceiver is available for use on all
audio and control interfaces, including the IP interface.
16 jotron.com Doc. No.: 103614 TR-910 Operator Rev. AB
