5.3 Basic OperaƟon
5.3 Basic Operaon
5.3.1 Turning the unit ON/OFF
There are four basic screens in the transceiver: Home screen, Volume screen, Funcon screen and Main menu.
When the transceiver is turned on, the home screen appears on the display. To turn the unit on, off or restart,
follow these instrucons:
• To turn the unit ON, press scroll/select for 1 second. The display lights up and, aer showing a splash
screen, the home screen appears.
• To turn the unit OFF, press scroll/select for 3 seconds to open the shutdown menu, then rotate to
Shutdown and press the Yes shortcut.
• To restart the unit, press scroll/select for 3 seconds to open the shutdown menu, then rotate to Restart
and press the Yes shortcut.
• In the unlikely event that the unit is frozen or unresponsive, press scroll/select for more than 10 seconds
to force shut down.
5.3.2 Home screen - Channel shortcuts
The home screen is the starng point to operate the radio and appears when the radio is turned on. The home
screen displays the operang frequency in the center, shortcut frequencies above corresponding shortcut keys
with acve shortcut highlighted at the boom, and indicator icons when acve at the right and le of the
display. Select desired shortcut channel by pressing corresponding shortcut key.
5.3.3 Volume screen - Seng audio volume level
The volume sengs are accessed by rotang scroll/select from the home screen. When opening the volume
screen, the previously adjusted audio output is selected, except for the first me aer boot. Then the audio
output acve with priority from le to right is selected. The integrated speaker is shown as the lemost icon,
and if a Mic/Headset or an external speaker is connected, the volume sengs are accessible from the second
and third icon from le. The fourth icon is display brightness/contrast and is described later in this secon.
The volume screen returns automacally aer a few seconds of inacvity.
Doc. No.: 103614 TR-910 Operator Rev. AB jotron.com 41
