1 Introducon
1.1 Design
The TR-910 is a compact, high-quality radio available in a variety of configuraons to meet the high demands
of the ATC and Oil and Gas industries where a small, rugged and durable radio unit is needed. The radio
has an all metal housing, making it very robust but sll light enough to be carried as a manpack. It is a fully
solid-state design based on a Soware-Defined Radio (SDR) concept, making it very versale, future proof and
firmware upgradeable. It also includes a LAN interface for remote configuraon and digital recording and is
fully compliant to ED-137 with the VoIP opon enabled.
TR-910 meets or outperforms all radio requirements specified in ETSI EN300676 and EN301489 (EMC). It
supports both 25kHz and 8.33kHz channels in accordance with ICAO recommendaons.
1.2 Applicaons
Listed below are some of the possible applicaons of the TR-910 radio:
• Installed as a desktop unit, with microphone and/or headphone connected to the front connector. An
external loudspeaker can be connected to the transceiver unit if required.
• Man Portable version, enclosed in a shoulder/carrying bag, with baery pack, antenna and microphone
(or headset) connected. An external baery charger can be connected for charging the baery pack as
and when required.
• Internally mounted in a vehicle, with microphone connected to the front module connector. An external
loudspeaker can be connected to the transceiver unit if required.
• Flush mounted on a horizontal or vercal plate, with microphone and/or headphone connected to the
front connector. An external loudspeaker can be connected to the transceiver unit if required.
• Remote configuraon and monitoring through the LAN interface via the Jotron Remote Control and
Monitoring System (RCMS).
• With VoIP opon is enabled, the TR-910 also fully supports ED-137 and facilitates up to two remote
sessions and two recording streams. It is possible to expand this funcon by the inclusion of ”Enhanced
VoIP”. This will increase the number of sessions to 4 and recording streams to 3.
1.3 Models covered by this manual
Table 7: Radio models covered by this manual
The following models /versions are covered by this manual
Model P/N Output Frequency Mode
TR-910 Desktop Radio (DE) 103400DE 10 Wa 118-137 MHz AM
TR-910 Man Portable Radio (MP) 103400MP 5Wa 118-137 MHz AM
TR-910 Vehicle Radio (VE) 103400VE 10 Wa 118-137 MHz AM
TR-910 Last Resort Radio (LR) 103400LR 10 Wa 118-137 MHz AM
TR-910 Subrack Radio (SR) 103400SR 10 Wa 118-137 MHz AM
TR-910 Last Resort Subrack Radio (LR-SR) 103400LR-SR 10 Wa 118-137 MHz AM
Doc. No.: 103614 TR-910 Operator Rev. AB jotron.com 13
