6-2 Adjusting the needle entry point
○
Remove the face cover.
Adjustmentprocedure
 1.Selectthestraightstitchusingthepatternselectingbutton.Choosecenterneedleposition.
 2.Assembleaneedle#14intotheneedlebar,loosenthesetscrewintheeccentriccollarandadjustthefeed
bareccentriccollarsothattheneedlemeetsthecenteroftheneedleslotinthethroatplatewhenitreach-
esthetopsurfaceofthethroatplatebyturningthehandwheel.
Setscrew
Feed bar eccentric collar
