– 5 –

○

Toremovethetopcover,bowthehingesectionoftherightsideofthecover.

○

Remove setscrews

and

from the face cover.

Then, remove the face cover.

○

Fittingaat-bladescrewdriver(T-shape)inthenearestslotinthethroatplate,

push up the throat plate with the screwdriver until it comes off.

Then remove the throat plate.

[4] Disassembling the machine covers

1) Top cover

2) Face cover

3) Throat plate

T-shape

❶

❷
