JUKI HZL-NX7 Service Manual

– 21 –
6-9 Clearance between the needle and the blade point of hook
○
Remove the face cover and the throat plate.
Adjustmentprocedure
1. Loosen screw
❶
.Adjusttheclearancebetweentheneedleandthebladepointofthehookto0.02to0.07
mmbyturningadjustingshaft
❷
.
Left needle position Right needle position Right needle positionLeft needle position
If the clearance is larger at the right needle
entry point, shift
❹
to the right.
If the clearance is larger at the left needle
entry point, shift
❹
to the left.
Adjustmentprocedure
1. Select No. 2: FAGOTT of the service mode.
 2.Graduallyturnadjustingshaft
❷
tondapositionwheretheneedledeviatesslightly.Now,temporarily
tighten screw
1
.
3. Slightly loosen setscrew
❸
.Adjustthelateralbalanceoftheneedlebarbyslightlymovingright-leftadjust-
er
❹
while carefully listening to the noise produced when the needle deviates at the right and left needle
entry points. Then, securely tighten setscrew
❸
.
4. Additionally turn shaft
❷
and securely tighten screw
❶
at the position where the needle does not deviate.
 5.LightlytapPsectionwithngers.Ifyouhearaneedledeviationnoiseattherightandleftneedleentry
points,theoptimumclearanceisprovidedbetweentheneedleandthehook.
❷
❹
❸
P section
Adjustingthebalanceoftheclearancesattherightandleftneedleentrypoints
 1.Selectthezigzagpatternandsetthezigzagwidthto7mm.Adjustthebalanceoftheclearancesprovided
betweentheneedleandthebladepointofthehookattherightandleftneedleentrypoints.
0.02 to 0.07 mm
❶
❷
❶
