JUKI LBH-1790 User Manual

– 142 –
5
Press the upper right position.
Press red circle (F) located at the upper right
position on the screen.
 Whennishingthecompensation,pressCANCEL
button (B).
6
Store the data.
When 4 points have been pressed, the screen
showing power-OFF prohibition is displayed since
the compensation data are to be stored.
Do not turn OFF the power while this screen is
being displayed.
When the power is turned OFF, the compensated
data are not stored.
 Whenstoringisnished,thecheckprogram
screen is automatically displayed.
B
F

JUKI LBH-1790 Specifications

General

Stitch Type	Lockstitch
Max Sewing Speed	4, 200 sti/min
Needle Bar Stroke	34.6 mm
Type	Industrial
Needle	DPx5
Motor	Servo Motor
Buttonhole Length	8 mm ~ 40 mm
