JUKI LBH-1790 User Manual

– 61 –
Button and display Description
A CONTINUOUS STITCHING DATA
NAME display
Name inputted to continuous stitching data during sewing is displayed.
B KNIFE CANCEL button Every time the button is pressed, dropping/non-dropping knife is
changed over alternately.
C PRESSER DOWN button Presser can be lowered and the knife down screen is displayed.
To raise the presser, press the presser up button displayed in the
presser down screen.
＊
When performing threading in this state, turn OFF the power before
performing.
D BOBBIN WINER button
Bobbin thread can be wound.
→
Refer to
11. WINDING BOBBIN THREAD, p.29
.
E CONTINUOUS STITCHING
PATTERN NO. display
Continuous stitching data No. during sewing is displayed.
F WITH/WITHOUT DOUBLE
STITCHING display
With/without double stitching which is set to the pattern data during
sewing is displayed.
G NUMBER OF TIMES OF BASTING
display
Number of times of basting which is set to the pattern data during
sewing is displayed.
H STEP STITCHING button
When the button is pressed, the step stitching screen to check the
needle entry point and to perform re-sewing is displayed.
→
Refer to
10. PERFORMING RE-SEWING, p.27
.
I NEEDLE THREAD TENSION
CHANGE button display
Needle thread tension which is set to the pattern data during sewing is
displayed.
J NUMBER OF TOTAL STITCHES
display
Number of total stitches of the continuous stitching data during sewing
is displayed.
K1 COUNTER VALUE CHANGE button
Existing counter value is displayed on this button. When the button is
pressed, the counter value change screen is displayed.
→
Refer to
12. USING COUNTER, p. 30
.
K2 COUNTER CHANGE OVER button
Display of sewing counter/No. of pcs. counter can be changed over.
→
Refer to
12. USING COUNTER, p. 30
.
L OVEREDGING WIDTH, LEFT button Overedging width, left which is set to the pattern data during sewing is
displayed.
M KNIFE GROOVE WIDTH, LEFT
display
Knife groove width, left which is set to the pattern data during sewing
is displayed.
N SEWING SHAPE display Sewing shape during sewing is displayed.

JUKI LBH-1790 Specifications

General

Stitch Type	Lockstitch
Max Sewing Speed	4, 200 sti/min
Needle Bar Stroke	34.6 mm
Type	Industrial
Needle	DPx5
Motor	Servo Motor
Buttonhole Length	8 mm ~ 40 mm
