– 8 –
2. ST
ANDARD
ADJUSTMENT
(1) Needle entry position
(2) Longitudinal position of the feed dog
Conditions
•
Needle bar at lowest dead point
•
Feed amount : 0 mm
Conditions
•
Needle bar at lowest dead point
•
Feed amount : 0 mm
Model
Dimension A
LU-1561N-7
1
1.5
±
0.1mm
LU-151
1N-7
1
1
±
0.1mm
LU-1509N
LU-1561N
10
±
0.1mm
LU-1509NH
LU-1510N-7
9
±
0.1mm
LU-1560N-7
LU-1560N
LU-1508N
8.5
±
0.1mm
LU-1510N
LU-1510NA-7
LU-1508NH
8
±
0.1mm
LU-1565N
60mm
T
op surface of
throat plate
A
a
a’
a = a’
Standard gauge type
LU-2200 gauge type
47mm
A
Standard Adjustment
Standard Adjustment
T
op surface of
throat plate
11
13
