3) Parts List
Removing parts list
Note No. Part No. Name of part Q’ty
1 21332309 Side plate cover 1
2 SS4110815SP Side plate cover setscrew 1
Note No. Part No. Name of part Q’ty
40025686 Automatic presser foot lifter (asm.) (1)
PA400150100 Automatic presser foot lifter cylinder 1
SM6082502TP Cylinder installing screw 4
21356506 Cylinder connecting screw 1
NM6080001SE Nut 1
SD0720331SP Hinge screw 1
21356605 Automatic presser foot lifter lever A 1
21356803 Automatic presser foot lifter lever B 1
SM6051002TP
Automatic presser foot lifter lever B setscrew
2
21356704 Automatic presser foot lifter lever shaft 1
PJ304065102 Elbow 2
21356308
Automatic presser foot lifter cylinder stay (front)
1
21356407
Automatic presser foot lifter cylinder stay (rear)
1
SS6151040SP Cylinder stay attaching screw 4
CM3002000B1 Caution seal for being caught 1
CM300200001 Caution seal for injury to finger 1
Automatic presser foot lifter components (List A)
Removing parts list
Set part No. of automatic presser foot lifter
(Caution : These set part Nos. are the set part Nos. of the parts from List A to List D.)
No. Set No. Name of set part Q’ty Set contents (List No.) Remarks
ABCD
1 40025686 AK134A kit 1 ❍❍ ❍
2 40025687 AK134B kit 1 ❍❍
3 40025688 AK134C kit 1 ❍❍❍
4 40025689 AK134D kit 1 ❍❍
* 1 : Part No. 40034306 (automatic reverse feed device set) is necessary as well.
Note No. Part No. Name of part Q’ty Remark
40025359 Cord (asm.) 1
GAKA14030A0 Solenoid valve (asm.) 1
GAK29010000 Quick joint (elbow) 1
GAK29015000 Quick joint (straight) 1
GAK29016000 Speed controller 1
BT0600401EB Air hose 2 1.3m
BT0600401EB Air hose 1 0.18m
HX00123000A Cord presser 1
PJ309065202 Quick joint (branch elbow Y) 1
SM4034001SN Solenoid valve setscrew 2
HX002950000 Wire mark 3 1
HX00295000A Wire mark 3 2
Pneumatic device components (List B)
Pneumatic device components (List C)
Note No. Part No. Name of part Q’ty
40024970 Pneumatic components (asm.) 1
Kit A (List D)
Note No. Part No. Name of part Q’ty
1 40025036 Presser foot lifter knee switch B (asm.) 1
2 SK3514000SC Knee switch (asm.) installing wood screw 2
In case of installing automatic reverse feed device
and automatic presser foot lifter after set-up of
machine *1
In case of installing automatic presser foot lifter
after set-up of machine
