– 1 –
No. Item Specifications
1 Model LU-1510N (Standard gauge type)
2Model name 1-needle, unison feed, lockstitch machine (automatic lubrication)
3 Application For heavy-weight materials
4 Sewing speed Max. 2,500 rpm
5 Needle SCHMETZ 135 X 17 Nm 125 to 180 Standard : Nm 160
Applicable thread size
for sewing
7 Stitch length Max. 9 mm (forward/reverse feed)
8 Presser foot lift Hand lifter : 9 mm Knee lifter : 16 mm
Stitch length adjusting
mechanism
Reverse stitch adjusting
method
11 Thread take-up Slide thread take-up
12 Needle bar stroke 36mm
2.5mm to 6.5mm
Alternate foot stroke adjusted by long hole
14 Hook Vertical-axis 2-fold hook (Latch type)
15 Feed mechanism Box feed
Top and bottom feed
actuation mechanism
17 Lubrication Automatic lubrication (partially by manual)
18 Lubricating oil JUKI New Defrix Oil No. 2 (equivalent to ISO standard VG32)
19 Bed size 517 mm x 178 mm
20 Space under the arm 255mm x99mm
21 Hand wheel size V belt effective diameter : ø93.3 mm Outer diameter : ø160 mm
22 Motor 2P, 400W, 4P,400W
1. SPECIFICATIONS
6 #30 to #5
9 By dial
10 By level
13 Alternate foot stroke
16 Timing belt
