In case of installing the automatic reverse feed device and the automatic presser foot lifter after set-up of machine
Pneumatic device components (List B)
*Type of the pneumatic device
• AK- ❑ ❑ ❑ A : Knee switch type
• AK- ❑ ❑ ❑ B : Pedal switch type
2) Installing the pneumatic device components
In case of installing the automatic presser foot lifter after set-up of machine
Pneumatic device components (List C)
o Pneumatic device used : AK-134A and AK-134B
• Install the device above in the form of adding to
the pneumatic components of the automatic re-
verse feed device.
o Pneumatic device used : AK-134C and AK-134D
• Install pneumatic components (asm.) as listed.
