Push the disc tray for DISC 3 to the back.
Push the disc tray gently to the back using the finger hold on the front
right of the tray. The disc tray for DISC 2 wiil appear below the disc «&
tray for DISC 3.
* Take care not to touch any CDs in the lower trays when pushing the
To Play a Disc
This function plays the disc in the Unit continuously, and lights the “CONTINUE” indicator.
ry OISC 1
Prepare the discs.
<=
a
D
2
D
D
a
pan
Lu
Lid
disc tray into the Unit.
* If excessive force is applied to the Main Tray, the Main Tray will be
closed. So, when you push the disc tray, gently push it to the back.
* While pushing the disc tray, take care not to touch any buttons on
the Unit.
Insert a CD into the disc tray for DISC 2 in the same way as for
DISC 3.
After inserting the CD, push the disc tray to the back. The dise tray for DISC 1 will appear.
Insert CD into the disc tray for DISC 1.
Press the ALL CD EJECT button.
The Main Tray returns to its original position.
* “ALL EJECT” appears on the display when the Main Tray is opened, and “ALL CLOSE” appears
when it closes.
¢ If you press the CD or » button on the unit (CD button on the Remote Control) instead of the
ALL CD EJECT button, the Main Tray is automatically closed and continuous play starts for the
lit disc marker. Also, if you press the DISC | - 3 buttons, the Main Tray will automatically close
and playback will start from that disc.
* If the Main Tray is open when the System switches to standby mode. the Main Tray is closed
automatically.
CAUTION: Do not push the disc tray for DISC 1 to the back. If the Main
Tray is pushed in with a CD in, the tray will not load properly or may be
ejected again after it has been pushed in. This can result in you not
being able to use the CD Player. If the CD Player does not respond,
disconnect the power cord then reconnect it again. The CD Player will
operate normally again.
CAUTION: While closing the Main Tray, take care not to nip any foreign
matter (headphone cable, etc.) between the Main Tray cover and the CD
Player. If a foreign matter is nipped, the CD Player may be inoperative.
In this case, remove it, and push the Main Tray cover to close the Main
Tray. Then, the CD Player will operate normally again.
To insert CDs individually:
Press the 4 button on the left of the DISC (1 - 3) button you want to
insert the disc into.
The disc tray for the selected disc number is set to the top and the Main Tray opens.
, Place a CD onto the tray.
Press the same 4 button again.
The Main Tray closes.
* Hf you press a different & button, the Main Tray closes then the disc tray for the 4 button pressed
1s opened.
If you press the ALL CD EJECT button, the Main Tray closes. Then the Main Tray opens again,
containing all disc trays.
Hi “Di OPEN” appears on the display when the Main Tray is opened (when DISC 1 is selected), and
“D1 CLOSE” appears when it closes.
/Press the DISC (1-3) button on the Unit or the Remote Control you
want to piay.
The first track of the selected disc will begin playing.
When the selected disc finishes playing, the next disc will begin playing automatically.
When the last disc has finished playing, the Unit will stop automatically.
To use Continuous Play from the first track of the disc selected by the disc marker, you do not need to
press a DISC (1-3) button, just press the CD or ® button (or CD or ® A* button on the Remote
Control).
* The » A button on the Remote Control can be used to control the CD Player when the Remote
Control is in CD mode..
Playing order of discs
MA When playback starts from DISC 1, the playing order is DISC | + DISC 2 + DISC 3. When DISC 3
has finished, the CD Player selects DISC 1 (the disc marker is on) and stops.
MA Wien playback starts from DISC 2, the playing order is DISC 2 - DISC 3 — DISC |. When DISC 1
has finished, the CD Player selects DISC 2 (the disc marker is on) and stops.
ME When playback starts from DISC 3, the playing order is DISC 3 -» DISC 1 + DISC 2. When DISC 2
has. finished, the CD Player selects DISC 3 (the disc marker is on) and stops.
* If any of the disc trays are empty, the CD Player skips that disc tray and continues through the
remaining disc trays in the order shown above.
Note: If there is no CD in the disc tray for the DISC (1-3) button you pressed, the message “NO DISC”
appears on the display and the tray for that disc is automatically moved to the top and the Main Tray
opens. If there is no disc in the disc tray for the selected disc number when the » or CD button (or the CD
or » A button on the Remote Control) is pressed, playback begins from the next disc.
To stop playing the disc, press the @ button (press the MW button after pressing the CD button
when using the Remote Control).
To stop play and remove the disc, press the button for the disc being played or press the ALL CD
EJECT button.
To pause, press the ® button. The Disc display will blink. (The Pause function cannot be used with the
» A button.on the Remote Control.)
To cancel pause, press the » button again or press the CD button (or the CD or » A button on the
Remote Control). Play. continues from the point where it was paused.
To Change Discs While Playing
You can replace a CD in a tray not being used, while another CD is playing.
Press the 4 button of the tray not being used.
The disc tray you selected is set to the top and the Main Tray opens.
Replace the disc in the tray.
Press the same 4 button again.
The Main Tray closes.
To Select a Track
Using the Unit
Press the cursor key to the right or left (<< < or > >>).
WH Set the tracks by pressing the Md < or > 1 cursor key to move between tracks.
* Pressing the > 1 cursor key moves to the next track.
* Pressing the #@ < cursor key moves to the previous track. (Moves to the beginning of the track
during playing a track.)
WE Pressing down either of these cursor keys scans the tracks.continuously. until the key is released.
Using the Remote Control
Press the < 4 << or >> PP! > button after pressing the CD button.
GE Each time you briefly press and release the < kd <4 or > m1 > button, the track changes by
one.
* Press and release the >» hi > button to go ahead one track at a time.
* Press and release the < «#4 button to go back one track at a time. (Moves to the beginning
of the track during playing a track.)
ME Holding down the ¢ 4 <4 or BP PP > button allows you to change tracks continuously.
23
