JVC SP-XT9 User Manual

3-40
Main board (DX-T5)
Block No. [0][8]
S5024 QSW1121-001Z PUSH SW I.M
S5025 QSW1121-001Z PUSH SW I.M
S5026 QSW1121-001Z PUSH SW I.M
S5027 QSW1121-001Z PUSH SW I.M
S5028 QSW1121-001Z PUSH SW I.M
S5029 QSW1121-001Z PUSH SW I.M
S5030 QSW1121-001Z PUSH SW I.M
S5031 QSW1121-001Z PUSH SW I.M
S5032 QSW1121-001Z PUSH SW I.M
S5033 QSW1121-001Z PUSH SW I.M
S5034 QSW1121-001Z PUSH SW I.M
SP500 GV40205-004A IC HOLDER
 Symbol No. Part No. Part Name Description Local
IC760 SN74AHCT08NS-X IC
IC770 MN101C49GFS1 MASK ROM
IC771 BR24L02F-W-X IC
IC810 CD4066BM-X IC
IC820 LC75342M-X IC
IC830 RC4558D-X IC
IC850 M65851FP IC
IC860 JCV8011-X IC
IC881 RC4558D-X IC
IC901 RC4580ID-X IC
Q7000 KTC3199/GL/-T TRANSISTOR
Q7010 KTC3199/GL/-T TRANSISTOR
Q7080 KRC107S-X DIGI TRANSISTOR
Q7081 KRC111S-X TRANSISTOR
Q7788 KRA102S-X DIGI TRANSISTOR
Q7798 KRA102S-X DIGI TRANSISTOR
Q8000 2SD2114K/VW/-X TRANSISTOR
Q8030 KTC3875/YG/-X SI TRANSISTOR
Q8031 KTC3875/YG/-X SI TRANSISTOR
Q8032 KTC3875/YG/-X SI TRANSISTOR
Q8037 KTC3875/YG/-X SI TRANSISTOR
Q8038 KTC3875/YG/-X SI TRANSISTOR
Q8040 2SD2114K/VW/-X TRANSISTOR
Q8100 2SD2114K/VW/-X TRANSISTOR
Q8130 KTC3875/YG/-X SI TRANSISTOR
Q8131 KTC3875/YG/-X SI TRANSISTOR
Q8132 KTC3875/YG/-X SI TRANSISTOR
Q8137 KTC3875/YG/-X SI TRANSISTOR
Q8138 KTC3875/YG/-X SI TRANSISTOR
Q8140 2SD2114K/VW/-X TRANSISTOR
Q8211 KRC104S-X TRANSISTOR
Q8212 KRC104S-X TRANSISTOR
Q8260 KTC3199/GL/-T TRANSISTOR
Q8524 KTC1027/OY/-T TRANSISTOR
Q8900 KRA104S-X DIGI TRANSISTOR
Q8910 2SD1328/ST/-X TRANSISTOR
Q8911 2SD1328/ST/-X TRANSISTOR
Q9001 2SD2114K/VW/-X TRANSISTOR
Q9002 2SD2114K/VW/-X TRANSISTOR
Q9003 KRC111S-X TRANSISTOR
Q9004 KTA1504/YG/-X SI TRANSISTOR
Q9100 KRA111S-X D. TRANSISTOR
Q9101 2SD2114K/VW/-X TRANSISTOR
Q9102 2SD2114K/VW/-X TRANSISTOR
Q9103 2SD2114K/VW/-X TRANSISTOR
Q9104 2SD2114K/VW/-X TRANSISTOR
D7000 1SS133-T2 SI DIODE
D7010 1SS133-T2 SI DIODE
D7050 MTZJ5.1B-T2 Z DIODE
D7080 1SS133-T2 SI DIODE
D7081 MTZJ4.7B-T2 Z DIODE
D7082 1SS133-T2 SI DIODE
D7151 1SS133-T2 SI DIODE
D7152 1SS133-T2 SI DIODE
 Symbol No. Part No. Part Name Description Local
D7390 1SS133-T2 SI DIODE
D7711 1SS133-T2 SI DIODE
D7713 1N4003S-T5 SI DIODE
D7784 MTZJ3.9B-T2 Z DIODE
D7785 MTZJ3.9B-T2 Z DIODE
D8230 1SS133-T2 SI DIODE
D8524 MTZJ5.6B-T2 Z DIODE
D8900 1SS133-T2 SI DIODE
D8901 1SS133-T2 SI DIODE
D9001 1SS133-T2 SI DIODE
D9002 1SS133-T2 SI DIODE
D9100 MTZJ2.4B-T2 Z DIODE
C7001 QETN1HM-476Z E CAPACITOR 47uF 50V M
C7002 QETN1HM-476Z E CAPACITOR 47uF 50V M
C7050 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7080 NCB31HK-102X C CAPACITOR 1000pF 50V K
C7082 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C7083 NCB31HK-103X C CAPACITOR 0.01uF 50V K
C7084 QETN0JM-227Z E CAPACITOR 220uF 6.3V M
C7085 QETN0JM-108Z E CAPACITOR 1000uF 6.3V M
C7710 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C7711 QETN1CM-107Z E CAPACITOR 100uF 16V M
C7712 NCS31HJ-180X C CAPACITOR 18pF 50V J
C7713 NCS31HJ-180X C CAPACITOR 18pF 50V J
C7788 QETN1HM-106Z E CAPACITOR 10uF 50V M
C7798 QETN1HM-106Z E CAPACITOR 10uF 50V M
C8001 QTE1V06-106Z E CAPACITOR 10uF 35V
C8002 QTE1V06-106Z E CAPACITOR 10uF 35V
C8020 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8021 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8022 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8023 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8025 QTE1H28-106Z E CAPACITOR 10uF 50V
C8026 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C8027 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C8028 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C8030 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C8031 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C8032 QTE1C06-226Z E CAPACITOR 22uF 16V
C8062 QTE1V06-106Z E CAPACITOR 10uF 35V
C8101 QTE1V06-106Z E CAPACITOR 10uF 35V
C8102 QTE1V06-106Z E CAPACITOR 10uF 35V
C8120 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8121 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8122 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8123 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8125 QTE1H28-106Z E CAPACITOR 10uF 50V
C8126 QFLC1HJ-272Z M CAPACITOR 2700pF 50V J
C8127 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C8128 QFLC1HJ-104Z M CAPACITOR 0.1uF 50V J
C8130 QFVF1HJ-154Z MF CAPACITOR 0.15uF 50V J
C8131 QFVF1HJ-124Z MF CAPACITOR 0.12uF 50V J
C8132 QTE1C06-226Z E CAPACITOR 22uF 16V
C8162 QTE1V06-106Z E CAPACITOR 10uF 35V
C8182 QFLC1HJ-471Z M CAPACITOR 470pF 50V J
C8221 QCBB1HK-103Y C CAPACITOR 0.01uF 50V K
C8222 QTE1C06-107Z E CAPACITOR 100uF 16V
C8230 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8232 QETN1HM-105Z E CAPACITOR 1uF 50V M
C8233 QFLC1HJ-683Z M CAPACITOR 0.068uF 50V J
C8261 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8262 QFLC1HJ-223Z M CAPACITOR 0.022uF 50V J
C8263 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C8264 QETN1HM-106Z E CAPACITOR 10uF 50V M
C8265 QETN1HM-106Z E CAPACITOR 10uF 50V M
C8266 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8267 QETN1EM-336Z E CAPACITOR 33uF 25V M
C8268 QETN1HM-224Z E CAPACITOR 0.22uF 50V M
C8269 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
C8360 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8361 QETN1HM-475Z E CAPACITOR 4.7uF 50V M
C8362 QETN1HM-474Z E CAPACITOR 0.47uF 50V M
C8363 QETN1EM-476Z E CAPACITOR 47uF 25V M
C8501 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C8503 QFLC1HJ-154Z M CAPACITOR 0.15uF 50V J
C8504 QFLC1HJ-152Z M CAPACITOR 1500pF 50V J
C8506 QETN1HM-225Z E CAPACITOR 2.2uF 50V M
 Symbol No. Part No. Part Name Description Local
